Description
FallTech 7534 is a steel anchor. FallTech lists it as meeting ANSI Z359.18-2017. Static strength 5,000 lb min.; ANSI User Capacity 130 to 310 lb max.; OSHA User Capacity 130 to 425 lb max. Sold individually.
FallTech 7534 specifications
| Item | FallTech data |
|---|---|
| Part number | 7534 |
| Product Type | I-beam Clamping |
| Standards | ANSI Z359.18-2017; OSHA 1926.502 and 1910.66 |
| Static Strength | 5,000 lb min. |
| ANSI User Capacity | 130 to 310 lb max. |
| OSHA User Capacity | 130 to 425 lb max. |
| D-Rings | Plated alloy steel; 5,000 lb min. static strength |
| Crossbar | Aluminum alloy |
| Clamp Jaws | Aluminum alloy |
| Product type | I-beam Clamping |
| Master pack | 4 per case |
Source: FallTech, Instruction manual (document).
Designed for temporary beam anchorage applications, this trailing beam anchor moves smoothly with the user while maintaining a secure connection to structural steel. Dual-clamp adjustment supports fast installation across a wide range of beam sizes.
Features
- Features threaded aluminum crossbar and jaws with knurled rings for fine adjustment
- Exclusive recessed under-jaw ball bearings provide improved mobility.
- Fits beam flanges from 3" to 18-1/4" wide and up to 1" thick
- For temporary mobile use on horizontal I-beams
- Complies with ANSI Z359.18-2017
Sold individually
The price shown is for one; quantity 1 = 1 piece.
Documents & downloads
Item Number
7534
