Description
Loctite 195776 is a threadlocker. Type Thread Sealants; capacity volume 50 mL; resistance Acetone, Ethanol, Ethylene Glycol, Motor Oil and more. Loctite lists 50 mL bottle, fluorescent blue color; Breakaway torque of 50 in lb.
Loctite 195776 specifications
| Item | Loctite data |
|---|---|
| Part number | 195776 |
| Type | Thread Sealants |
| Color | Fluorescent Blue |
| Capacity Volume | 50 mL |
| Resistance | Acetone; Ethanol; Ethylene Glycol; Motor Oil; Phosphate Ester; Water |
| Applicable Materials | Steel; Metal |
| Chemical Compound | Acrylic Ester |
| Container Size | 50 mL |
| Curing Method | Anaerobic |
| Gap Fill (max) | 0.05 mm |
| Torque (break) | 50 in lb |
| Torque (prevail) | 40 - 100 in lb |
| Viscosity (max) | 25 cP |
| Viscosity (min) | 10 cP |
| Width | 1.103 in |
| Height | 2.252 in |
Source: Loctite published product data.
Loctite Grade C is a fluorescent blue, medium-strength, low-viscosity threadlocker for fine-threaded nuts, bolts, and studs.
- 50 mL bottle, fluorescent blue color
- Low viscosity suited to fine threads
- Anaerobic, one-component formula that requires no mixing
- Resists acetone, ethanol, ethylene glycol, and motor oil
- Breakaway torque of 50 in lb
Locks, seals, and retains fine-threaded fasteners, with fluorescence that helps confirm application under UV light. Manufacturer item number: 195776. Sold by the bottle.
