Description
Miller MTL-OHS1-38 is a self-retracting lifeline. Miller lists it as meeting OSHA 1910.140 and ANSI Z359.14-2021. Lifeline material Polyester; anchor connector Aluminum Carabiner; harness connector Aluminum Carabiner. Miller lists Quick-activating stainless steel braking mechanism for immediate response; High-impact resistant nylon housing and abrasion-resistant webbing; Meets OSHA, ANSI Z359.14-2021 Class 1, and CSA standards; Supports up to 420 lbs per OSHA standards.
Miller MTL-OHS1-38 specifications
| Item | Miller data |
|---|---|
| Part number | MTL-OHS1-38 |
| Lifeline Material | Polyester |
| Anchor Connector | Aluminum Carabiner |
| Harness Connector | Aluminum Carabiner |
| Standards | OSHA 1926.502; OSHA 1910.140 |
| Dimensions (each) | 12.75 x 9.81 x 4.88 in |
| Weight | 4.19 lb |
| Dual SRL | No |
| Leading Edge Rated | No |
Source: Miller published product data.
Related Miller part numbers
| Part number | Version | Lifeline Material | Anchor Connector | Dimensions (each) |
|---|---|---|---|---|
| MTL-OHS1-38 | TurboLite+ Scorpion Self-Retracting Lifelines | Polyester | Aluminum Carabiner | 12.75 x 9.81 x 4.88 in |
| MTL-OHS1-05 | TurboLite+ Scorpion Self-Retracting Lifelines | Vectran™ Polyester Webbing | Steel Swivel Snap Hook | 12.75 x 9.75 x 4.75 in |
| MTL-OHS1-09 | TurboLite+ Scorpion Self-Retracting Lifelines | Vectran™ Polyester Webbing | Steel Locking Snap Hook | 12.75 x 9.81 x 4.88 in |
| MTL-OHS1-71 | TurboLite+ Scorpion Self-Retracting Lifelines | Vectran™ Polyester Webbing | Steel Locking Snap Hook | 12.75 x 9.81 x 4.88 in |
By Miller's published data; each part number links to its own page.
Miller MTL-OHS1-38 questions
What is the Miller MTL-OHS1-38? Miller MTL-OHS1-38 is a self-retracting lifeline. Miller lists it as meeting OSHA 1910.140 and ANSI Z359.14-2021.
What standards does the MTL-OHS1-38 meet? Miller lists OSHA 1926.502; OSHA 1910.140.
Which other Miller part numbers are in this family? MTL-OHS1-05 (turbolite+ scorpion self-retracting lifelines), MTL-OHS1-09 (turbolite+ scorpion self-retracting lifelines), MTL-OHS1-71 (turbolite+ scorpion self-retracting lifelines).
Scorpion Personal Fall Limiters (PFL) are a compact, lightweight self-retracting lifeline designed for workers up to 420 lbs. They provide greater mobility and versatility compared to traditional lanyards. Featuring a quick-activating stainless steel braking system, this PFL arrests free falls effectively. The unit includes a visual load indicator for safety and can be attached directly to a harness D-ring or used as a retractable lifeline on an anchor point.
- Quick-activating stainless steel braking mechanism for immediate response
- Visual load indicator alerts when the unit needs removal from service
- Compact design offers greater freedom compared to shock-absorbing lanyards
- Versatile option that can connect to harness D-ring or anchor point
- High-impact resistant nylon housing and abrasion-resistant webbing
- Meets OSHA, ANSI Z359.14-2021 Class 1, and CSA standards
- Supports up to 420 lbs per OSHA standards
- Ideal for industries such as construction, manufacturing, telecom, and wind energy, ensuring safety during work at heights
Manufacturer item number: MTL-OHS1-38. Sold individually.
