Description
PIP 9100-524PYR is an arc flash jacket made of pyrad. PIP lists it as meeting NFPA 70E, ASTM F1506, ASTM F1959 and OSHA 1910.269. Fabric weight 9oz; arc test method ATPV; Arc PPE Category 4. PIP lists ARC Rating: PPE 4, ATPV 40 cal/cm²; 2% carbon fibers adds strength and durability without extra weight; Meets NFPA 70E, ASTM F1506, ASTM F1959, OSHA 1910.269. Sizes Small, Medium, Large, X-Large, 2X-Large and 3X-Large.
PIP 9100-524PYR specifications
| Item | PIP data |
|---|---|
| Part number | 9100-524PYR (size and colour versions: 9100-524PYR-GR/S, 9100-524PYR-GR/M, 9100-524PYR-GR/L, 9100-524PYR-GR/XL, 9100-524PYR-GR/2X, 9100-524PYR-GR/3X) |
| Fabric Weight | 9oz |
| Arc Test Method | ATPV |
| Arc PPE Category | 4 |
| Arc Rating (cal/cm2) | 40 cal/cm² |
| Closure | Zipper |
| Fabric | Pyrad |
| Garment Type | Jackets |
| Gender | Men |
| Color | Gray |
| Standards | NFPA 70E; ASTM F1506 |
| Dimensions (each) | 17.72 x 13.78 x 1.18 in |
| Sizes | Small, Medium, Large, X-Large, 2X-Large and 3X-Large |
Source: PIP published product data.
Related PIP part numbers
| Part number | Version | Fabric Weight | Arc Test Method | Arc PPE Category |
|---|---|---|---|---|
| 9100-524PYR | PYRAD Arc Flash Jackets | 9oz | ATPV | 4 |
| 9100-524ULT | Arc Flash Jackets | 14oz | ATPV | 4 |
By PIP's published data; each part number links to its own page.
PIP 9100-524PYR questions
What is the PIP 9100-524PYR? PIP 9100-524PYR is an arc flash jacket made of pyrad. PIP lists it as meeting NFPA 70E, ASTM F1506, ASTM F1959 and OSHA 1910.269.
What sizes does the 9100-524PYR come in? Small, Medium, Large, X-Large, 2X-Large and 3X-Large. The size is the part-number ending: 9100-524PYR-GR/S, 9100-524PYR-GR/M, 9100-524PYR-GR/L.
What standards does the 9100-524PYR meet? PIP lists NFPA 70E; ASTM F1506.
Which other PIP part numbers are in this family? 9100-524ULT (arc flash jackets).
This garment is made with the NEW Arc Rated PYRAD® fabric by GORE-TEX Labs®, which features an innovative 3-layer laminate technology in a single ply. This advanced technology blocks heat during arc exposure, forming a protective carbonaceous char to reduce heat transfer to the skin, ensuring maximum safety and comfort.
- ARC Rating: PPE 4, ATPV 40 cal/cm²
- PYRAD® by GORE-TEX Labs® single-layer, 9.4 oz. fabric provides reliable thermal protection
- 2% carbon fibers adds strength and durability without extra weight
- 20% lighter than other premium products delivering 40 cal arc protection under 10 oz
- Ergonomic design reduces fatigue and improves ease of movement
- Highly breathable design tested for comfort using Hohenstein RET values
- Nomex® zipper adds flame resistance and durable, melt-proof protection
- Meets NFPA 70E, ASTM F1506, ASTM F1959, OSHA 1910.269
Manufacturer item number: 9100-524PYR. Select a size or color to see the exact item number. Sold individually. Case quantity: 10.
Item Numbers
Variant item numbers:
9100-524PYR-GR/S – Small
9100-524PYR-GR/M – Medium
9100-524PYR-GR/L – Large
9100-524PYR-GR/XL – X-Large
9100-524PYR-GR/2X – 2X-Large
9100-524PYR-GR/3X – 3X-Large
