Description
Safewaze 019-12009 is a kit. Safewaze lists it as meeting ANSI Standards. System weight 37.8 lbs. (17.1 kg); ANSI Weight Capacity 130-310 lbs. (59-141 kg); OSHA Weight Capacity Up to 420 lbs. (191 kg). Safewaze lists 2-person top bracket with an energy-absorbing, powder-coated head unit; 3/8 inch corrosion-resistant galvanized steel cable with a pre-swaged termination; 3,600 lb. single-user anchor point; 620 lb. system capacity.
Safewaze 019-12009 specifications
| Item | Safewaze data |
|---|---|
| Part number | 019-12009 |
| Material | Zinc plated steel, galvanized steel, stainless steel, aluminum |
| System Weight | 37.8 lbs. (17.1 kg) |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| System Capacity | Up to 620 lbs. (281 kg) |
| ANSI Standards | ANSI A14.3 |
| OSHA Standards | OSHA 1910.140; OSHA 1910.29; OSHA 1926.1053; OSHA 1926.502 |
| Length | 100' (30.5 m) |
Source: Safewaze, Technical Data Sheet 019-12001-12009-TDS (PDF) (document).
Reaching the full 100 feet, this Safewaze Ladder Climb System is a complete 2-person cable kit. It installs on standard rung attachments to equip a tall fixed ladder with a full cable fall arrest system.
- 2-person top bracket with an energy-absorbing, powder-coated head unit
- 3/8 inch corrosion-resistant galvanized steel cable with a pre-swaged termination
- 3,600 lb. single-user anchor point; 620 lb. system capacity
- Tension-retaining base bracket adjusts automatically to conditions
- All mounting hardware and a product inspection label included
Cable sleeves and intermediate guides are sold separately for this galvanized 100 foot kit. Manufacturer item number: 019-12009. Sold individually.
