Description
Safewaze 022-6061 is a rescue kit. Safewaze lists it as meeting ANSI Z359.4-2013, OSHA 1910.140 and ANSI Standards. Device Aluminum, stainless steel, nylon; top connector Steel swivel carabiner; rope connector 5,000 lb. steel carabiner. Safewaze lists Aluminum descent device with steel swivel carabiner and lifting wheel for disconnection; 9.3 mm nylon/polyester kernmantle rope, 150' (46 m) long, weighs 25.1 lbs. (11.4 kg); a 3' reinforced cross arm strap anchor and rope protector; ANSI Z359.4-2013 and OSHA 1910.140/1926.502 compliant; two-person capacity up to 620 lbs. (281 kg).
Safewaze 022-6061 specifications
| Item | Safewaze data |
|---|---|
| Part number | 022-6061 |
| Device | Aluminum, stainless steel, nylon |
| Top Connector | Steel swivel carabiner |
| Rope Connector | 5,000 lb. steel carabiner |
| Pick-Off Connector | 5,000 lb. aluminum carabiner |
| Web Connector | Dyneema® webbing |
| Rope | 9.3 mm nylon/polyester kernmantle |
| Cross Arm Strap Anchor | 5,000 lb. polyester |
| Pole | Aluminum pole, stainless steel head bracket |
| Tool Attachment | Polyester webbing, steel D-ring |
| Tool Tether | Elasticated polyester webbing, aluminum carabiners |
| Bag/Rope Protector | Water repellant tarpaulin |
| Anchor Strength Requirement | 3,100 lbs. (1400 kg) |
| Max Descent Length | 525' (160m) |
| Max Lifting Capacity | 85 lbs. - 15'; 310 lbs. - 10'; 420 lbs. - 5'; 620 lbs. - 3' |
| Max Number of Users | 2 |
| 1 Person Weight Capacity | 110-310 lbs. (50-141 kg) |
| 2 Person Weight Capacity | Up to 620 lbs. (281 kg) |
| ANSI Standards | ANSI Z359.4-2013 |
| OSHA Standards | OSHA 1910.140; OSHA 1926.502 |
| Length | 150' (46 m) |
| Weight | 25.1 lbs. (11.4 kg) |
Source: Safewaze, Technical Data Sheet 022-6061-6065-TDS (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Device | Top Connector | Rope Connector |
|---|---|---|---|---|
| 022-6061 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6060 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6062 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6063 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6064 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6059 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
| 022-6065 | Rescue Kits | Aluminum, stainless steel, nylon | Steel swivel carabiner | 5,000 lb. steel carabiner |
By Safewaze's published data; each part number links to its own page.
The Safewaze 150' Rescue/Descent Kit expands on a basic descent device with a full pick-off pole rescue setup. Both descent and lifting functions are rated for one or two workers.
- Aluminum descent device with steel swivel carabiner and lifting wheel for disconnection
- 9.3 mm nylon/polyester kernmantle rope, 150' (46 m) long, weighs 25.1 lbs. (11.4 kg)
- Includes a 3' reinforced cross arm strap anchor and rope protector
- ANSI Z359.4-2013 and OSHA 1910.140/1926.502 compliant; two-person capacity up to 620 lbs. (281 kg)
- Adds a 4-18' telescoping pick-off pole, pole head, aluminum carabiner, and web connector
It is suited to rescue teams that need both a controlled descent and a pole-assisted pick-off in one kit. Manufacturer item number: 022-6061. Sold individually as a single unit.
