Description
Safewaze 023-12154 is a hatch system. Safewaze lists it as meeting ANSI Standards. System length 10' to 20' (3.0 m to 6.1 m); system capacity 600 lbs. (272.2 kg). Safewaze lists Powder-coated steel construction with zinc-plated steel fasteners; 600 lb. system capacity.
Safewaze 023-12154 specifications
| Item | Safewaze data |
|---|---|
| Part number | 023-12154 |
| Material | Powder coated steel, zinc plated steel fasteners |
| System Length | 10' to 20' (3.0 m to 6.1 m) |
| System Capacity | 600 lbs. (272.2 kg) |
| Weight | 41.0 lbs. (18.6 kg) |
Source: Safewaze, Technical Data Sheet Belmont-Safety-Hatch-with-Flat-Brackets (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | System Length | System Capacity |
|---|---|---|---|---|
| 023-12154 | 10' to 20' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 10' to 20' (3.0 m to 6.1 m) | 600 lbs. (272.2 kg) |
| 023-12157 | 10' to 20' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 10' to 20' (3.0 m to 6.1 m) | 600 lbs. (272.2 kg) |
| 023-12160 | 10' to 20' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 10' to 20' (3.0 m to 6.1 m) | 600 lbs. (272.2 kg) |
| 023-12155 | 20' to 27' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 20' to 27' (6.1 m to 8.2 m) | 600 lbs. (272.2 kg) |
| 023-12158 | 20' to 27' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 20' to 27' (6.1 m to 8.2 m) | 600 lbs. (272.2 kg) |
| 023-12161 | 20' to 27' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 20' to 27' (6.1 m to 8.2 m) | 600 lbs. (272.2 kg) |
| 023-12156 | 27' to 34' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 27' to 34' (8.2 m to 10.4 m) | 600 lbs. (272.2 kg) |
| 023-12162 | 27' to 34' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 27' to 34' (8.2 m to 10.4 m) | 600 lbs. (272.2 kg) |
| 023-12159 | 27' to 34' Belmont Safety Hatch System | Powder coated steel, zinc plated steel fasteners | 27' to 34' (8.2 m to 10.4 m) | 600 lbs. (272.2 kg) |
By Safewaze's published data; each part number links to its own page.
Safewaze 023-12154 questions
What is the Safewaze 023-12154? Safewaze 023-12154 is a hatch system. Safewaze lists it as meeting ANSI Standards.
What is the 023-12154 made of? Powder coated steel, zinc plated steel fasteners, per Safewaze.
Which other Safewaze part numbers are in this family? 023-12157 (10' to 20' belmont safety hatch system), 023-12160 (10' to 20' belmont safety hatch system), 023-12155 (20' to 27' belmont safety hatch system), 023-12158 (20' to 27' belmont safety hatch system), 023-12161 (20' to 27' belmont safety hatch system).
This Belmont Safety Hatch System lets a worker open, close, and lock a roof hatch from ground level on a 10 to 20 foot fixed ladder. A manually cranked drive unit and a built-in extension pole give a smooth, hands-free transition from ladder to roof, and this kit uses flat brackets for side mounting on flat bar stock up to 4 inches.
- Fits fixed ladders from 10' to 20' (3.0 to 6.1 m) and hatches from 30 to 36 inches square
- Powder-coated steel construction with zinc-plated steel fasteners
- 600 lb. system capacity
- Includes 6 flat-bar side-mount brackets, a lifting tube extension, 2 intermediate guide brackets, and a drill bit rivet adapter
- Assembly required; padlock not included
Roofing and mechanical contractors install it so climbers never have to reach for the hatch while still on the ladder. Manufacturer item number: 023-12154. Sold individually.
Technical Data Sheet Belmont-Safety-Hatch-with-Flat-Brackets (PDF)
User Manual 220-00094-Belmont-Safety-Hatch-System-Manual (PDF)
