Description
Safewaze FS-FSP1230-G is a self-retracting lifeline. Safewaze lists it as meeting ANSI Z359.14-2021, OSHA 1910.140 and ANSI Standards. ANSI Weight Capacity 130-310 lbs. (59-141 kg); OSHA Weight Capacity Up to 420 lbs. (191 kg). Safewaze lists Steel carabiner, polymer housing, 3/16 in. galvanized steel cable, steel snap hook; 30 ft. (13.6 m) length; 10.1 lbs. (4.6 kg); ANSI weight capacity 130-310 lbs., OSHA capacity up to 420 lbs; Meets ANSI Z359.14-2021 and OSHA 1910.140, 1910.66, 1926.502.
Safewaze FS-FSP1230-G specifications
| Item | Safewaze data |
|---|---|
| Part number | FS-FSP1230-G |
| Material | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.14-2021 |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Length | 30' (13.6 m) |
| Weight | 10.1 lbs. (4.6 kg) |
Source: Safewaze, Technical Data Sheet Class 1 Overhead SRL, Northstar Classic FS-FSP1230-G V2 (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | ANSI Weight Capacity | OSHA Weight Capacity |
|---|---|---|---|---|
| FS-FSP1230-G | Self-Retracting Lifelines 30' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-FSP1250-G | Self-Retracting Lifelines 50' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-FSP1220-G | Self-Retracting Lifelines 20' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-FSP1265-G | Self-Retracting Lifelines 65' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-FSP1420-W | Self-Retracting Lifelines 20' Web SRL | Steel carabiner, polymer housing, 1" UHMPE webbing, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-FSP1215-G | Self-Retracting Lifelines 15' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
By Safewaze's published data; each part number links to its own page.
Safewaze FS-FSP1230-G questions
What is the Safewaze FS-FSP1230-G? Safewaze FS-FSP1230-G is a self-retracting lifeline. Safewaze lists it as meeting ANSI Z359.14-2021, OSHA 1910.140 and ANSI Standards.
What is the FS-FSP1230-G made of? Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook, per Safewaze.
Which other Safewaze part numbers are in this family? FS-FSP1250-G (self-retracting lifelines 50' cable srl), FS-FSP1220-G (self-retracting lifelines 20' cable srl), FS-FSP1265-G (self-retracting lifelines 65' cable srl), FS-FSP1420-W (self-retracting lifelines 20' web srl), FS-FSP1215-G (self-retracting lifelines 15' cable srl).
The Safewaze Northstar Classic 30-foot cable SRL steps up working range for tasks that keep workers farther from their anchor point.
- Steel carabiner, polymer housing, 3/16 in. galvanized steel cable, steel snap hook
- 30 ft. (13.6 m) length; 10.1 lbs. (4.6 kg)
- ANSI weight capacity 130-310 lbs., OSHA capacity up to 420 lbs.
- Meets ANSI Z359.14-2021 and OSHA 1910.140, 1910.66, 1926.502
A galvanized steel cable and non-corrosive housing suit crews working outdoors on roofing and pipeline jobs. Manufacturer item number: FS-FSP1230-G. Sold individually.
Technical Data Sheet Class 1 Overhead SRL, Northstar Classic FS-FSP1230-G V2 (PDF)
