Description
Western Enterprises AW430 falls under welding hose fittings and is made of brass. Connection type Female/Female; connection 1/4 in NPT to B-Size CGA-032, CGA-030 to A-Size(3/8 in - 24); pressure (max) 200 PSIG. Western Enterprises lists Made from brass to ensure functionality and durability; Can accommodate up to 200 psig of pressure. Available in 2 versions.
Western Enterprises AW430 specifications
| Item | Western Enterprises data |
|---|---|
| Part number | AW430 (size and colour versions: AW430B, AW430A) |
| Body Material | Brass |
| Connection Type | Female/Female |
| Connection | 1/4 in NPT to B-Size CGA-032; CGA-030 to A-Size(3/8 in - 24) |
| Pressure (max) | 200 PSIG |
| Shape | Straight |
| Size 1 | B-Size; A-Size |
| Thread Direction | RH; RH to RH |
| Sizes | CGA-032, CGA-030 to A-Size(3/8 in - 24); pressure (max) 200 PSIG |
Source: Western Enterprises published product data.
Western Enterprises Inert Arc Hose Couplers, available in the versions listed below.
FEATURES
- Made from brass to ensure functionality and durability
- Can accommodate up to 200 psig of pressure
Manufacturer item number: AW430B. Select a version to see the exact item number.
Available in 2 versions:
- B-Size, RH – AW430B
- A-Size, RH to RH – AW430A
