Western Enterprises Female NPT Outlet Adaptors for Manifold Pipelines

Name: Western Enterprises Female NPT Outlet Adaptors for Manifold Pipelines
Brand: Western Enterprises
Availability: InStock

Item # shown once options are selected ⚠ Prop 65

$6.32 - $10.28

Western Enterprises Female NPT Outlet Adaptors for Manifold Pipelines, available in the versions listed below.

FEATURES

Female NPT outlet adaptors for manifold pipelines have a LH or RH thread direction
Female adaptors can withstand pressures up to 3000 psig
Adaptors can be used with oxygen gases
It is made of a brass material for maximum durability

Manufacturer item number: 4161. Select a version to see the exact item number.

Available in 3 versions:

CGA-580, 3, 000 psig – 4161
CGA-540, 3, 000 psig – 4151
CGA-320, 3000 PSIG – CO21

Specifications

Body Material: Brass

CGA No.: CGA-580; CGA-540; CGA-320

Connection Type: Female/Female; Male/Female

Connections: 0.965 in Male; 1/4 in (NPT) Female; 0.903 in Male; 1/4 in (NPT) Female; 0.825 in Male; 1/4 in (NPT) Female

Female Thread: 1/4 in (NPT)

Gas Type: Argon; Helium; Nitrogen; Oxygen; Carbon Dioxide

Male Thread: 0.965 in; 0.903 in; 0.825 in

Pressure (max): 3,000 psig

Shape: Straight

Size 1: 1/4 in

Thread - TPI or Pitch: 0.965 in - 14 NGO, RH(F); 0.903 in - 14 NGO, RH(M); 0.825 in - 14 NGO, RH(M)

Thread Direction: RH

Type: Adapter

Current Stock:

Quantity:

Adding to cart… The item has been added

Specifications

Body Material	Brass
CGA No.	CGA-580; CGA-540; CGA-320
Connection Type	Female/Female; Male/Female
Connections	0.965 in Male; 1/4 in (NPT) Female; 0.903 in Male; 1/4 in (NPT) Female; 0.825 in Male; 1/4 in (NPT) Female
Female Thread	1/4 in (NPT)
Gas Type	Argon; Helium; Nitrogen; Oxygen; Carbon Dioxide
Male Thread	0.965 in; 0.903 in; 0.825 in
Pressure (max)	3,000 psig
Shape	Straight
Size 1	1/4 in
Thread - TPI or Pitch	0.965 in - 14 NGO, RH(F); 0.903 in - 14 NGO, RH(M); 0.825 in - 14 NGO, RH(M)
Thread Direction	RH
Type	Adapter
Prop 65 Warning	Yes
