Description
FallTech 7533 is a steel anchor. FallTech lists it as meeting ANSI Z359.18-2017. Static strength 5,000 lb min.; ANSI User Capacity 130 to 310 lb max.; OSHA User Capacity 130 to 425 lb max. Sold individually.
FallTech 7533 specifications
| Item | FallTech data |
|---|---|
| Part number | 7533 |
| Product Type | I-beam Clamping |
| Standards | ANSI Z359.18-2017; OSHA 1926.502 and 1910.66 |
| Static Strength | 5,000 lb min. |
| ANSI User Capacity | 130 to 310 lb max. |
| OSHA User Capacity | 130 to 425 lb max. |
| D-Rings | Plated alloy steel; 5,000 lb min. static strength |
| Crossbar | Aluminum alloy |
| Clamp Jaws | Aluminum alloy |
| Product type | I-beam Clamping |
| Master pack | 1 |
Source: FallTech, Instruction manual (document).
Designed for temporary beam anchorage applications, this trailing beam anchor moves smoothly with the user while maintaining a secure connection to structural steel during horizontal movement and positioning work.
Features
- Features threaded aluminum crossbar and jaws with knurled rings for fine adjustment
- Exclusive recessed under-jaw ball bearings provide improved mobility.
- Fits beam flanges from 3" to 12-1/4" wide and up to 1" thick
- For temporary mobile use on horizontal I-beams
- Complies with ANSI Z359.18-2017
Sold individually
The price shown is for one; quantity 1 = 1 piece.
Documents & downloads
Item Number
7533
