Description
The Loctite 290 Medium-Strength Wicking Grade Threadlockers are threadlockers. Capacity volume 10 mL, 50 mL, 250 mL; min temperature -65° F; max temperature 300° F. Loctite lists Product cures when confined in the absence of air between close-fitting metal surfaces; Can also fill porosities in welds, castings and powdered metal parts. Available in 3 versions.
Specifications
| Item | Loctite data |
|---|---|
| Color | Green |
| Capacity Volume | 10 mL; 50 mL; 250 mL |
| Min Temperature | -65° F |
| Max Temperature | 300° F |
| Resistance | Corrosion; Rust |
| Chemical Compound | Acrylic; Dimethacrylate Ester |
| Curing Method | Anaerobic |
| Fix Cure Time @ Temp. | 20 min at 72° F |
| Gap Fill (max) | 0.003 in |
| Thread Size (max) | 1/2 in |
| Thread Size (min) | < 1/2 in |
| Torque (break) | 90 in·lb on M10 Steel |
| Torque (prevail) | 260 in·lb on M10 Steel |
| Width | 1 in; 1.05 in; 1.8 in |
| Height | 3.6 in; 6.3 in; 8.8 in |
Source: Loctite published product data.
Loctite 290 is a medium/high-strength wicking grade threadlocker that flows between engaged threads by capillary action, so fasteners can be locked without disassembly. It resists loosening from shock and vibration across -65 to 300 degrees F, in 10, 50 and 250 mL bottles.
- Medium/high strength, wicking grade threadlocker designed for locking and sealing threaded fasteners
- Because of its low viscosity and capillary action, the product wicks between engaged threads and eliminates the need for disassembly prior to application
- Product cures when confined in the absence of air between close-fitting metal surfaces
- Prevents loosening and leakage due to shock and vibration
- Can also fill porosities in welds, castings and powdered metal parts
Available in 3 versions. Choose one from the list to see the exact item number and price.
Item Numbers
Variant item numbers:
233731 – 10 mL
135392 – 50 mL
135393 – 250 mL
