Description
Safewaze 021-4043 is a specialty specialty made of zinc-plated steel. Safewaze lists it as meeting ANSI Z359.18-2017 and ANSI Standards. Plate dimensions 6" x 4" x 1/4"; minimum breaking strength 10,000 lbs.; ANSI Weight Capacity 130-310 lbs. (59-141 kg). Safewaze lists Zinc-plated steel construction, 1.9 lbs; Back plate measures 6 inch x 4 inch x 1/4 inch; 10,000 lb. minimum breaking strength; Rated to ANSI Z359.18-2017 Type A; ANSI weight capacity 130-310 lbs., OSHA up to 420 lbs.
Safewaze 021-4043 specifications
| Item | Safewaze data |
|---|---|
| Part number | 021-4043 |
| Material | Zinc-plated steel |
| Plate Dimensions | 6" x 4" x 1/4" |
| Minimum Breaking Strength | 10,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.18-2017 Type A |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Weight | 1.9 lbs. (839 g) |
Source: Safewaze, Technical Data Sheet 021-4043-TDS (PDF) (document).
Combining the 10K Swivel Anchor with a back plate assembly, this Safewaze anchor mounts to reinforced cinder block, chillers, AC units or metal structure walls from 4 to 12 inches thick.
- Zinc-plated steel construction, 1.9 lbs.
- Back plate measures 6 inch x 4 inch x 1/4 inch
- 10,000 lb. minimum breaking strength
- Rated to ANSI Z359.18-2017 Type A; ANSI weight capacity 130-310 lbs., OSHA up to 420 lbs.
- Fastens with a 5/8 inch bolt and wingnut, maximum span 12 inches
Useful for HVAC and mechanical contractors needing a through-wall anchor near rooftop equipment. Manufacturer item number: 021-4043. Sold individually.
