Description
Safewaze FS-EX10-100-G is a self-retracting lifeline. Safewaze lists it as meeting ANSI Z359.14-2021, OSHA 1910.140 and ANSI Standards. ANSI Weight Capacity 130-310 lbs. (59-141 kg); OSHA Weight Capacity Up to 420 lbs. (191 kg). Safewaze lists Steel carabiner, polymer housing, 3/16 in. galvanized steel cable, steel snap hook; 100 ft. (30.5 m) length; 30.4 lbs. (13.8 kg); ANSI weight capacity 130-310 lbs., OSHA capacity up to 420 lbs; Meets ANSI Z359.14-2021 and OSHA 1910.140, 1910.66, 1926.502.
Safewaze FS-EX10-100-G specifications
| Item | Safewaze data |
|---|---|
| Part number | FS-EX10-100-G |
| Material | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.14-2021 |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Length | 100' (30.5 m) |
| Weight | 30.4 lbs. (13.8 kg) |
Source: Safewaze, Technical Data Sheet Class 1 Overhead SRL, Northstar Classic FS-EX10-100-G V2 (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | ANSI Weight Capacity | OSHA Weight Capacity |
|---|---|---|---|---|
| FS-EX10-100-G | Self-Retracting Lifelines 100' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
| FS-EX1080-G | Self-Retracting Lifelines 80' Cable SRL | Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook | 130–310 lb (59–141 kg) | Up to 420 lb (191 kg) |
By Safewaze's published data; each part number links to its own page.
Safewaze FS-EX10-100-G questions
What is the Safewaze FS-EX10-100-G? Safewaze FS-EX10-100-G is a self-retracting lifeline. Safewaze lists it as meeting ANSI Z359.14-2021, OSHA 1910.140 and ANSI Standards.
What is the FS-EX10-100-G made of? Steel carabiner, polymer housing, 3/16" galvanized steel cable, steel snap hook, per Safewaze.
Which other Safewaze part numbers are in this family? FS-EX1080-G (self-retracting lifelines 80' cable srl).
At 100 feet, the Safewaze Northstar Classic cable SRL gives crews maximum working range for cable self-retracting lifeline fall protection at height. A swivel top and load-indicating hook mark it as part of the Northstar Classic line.
- Steel carabiner, polymer housing, 3/16 in. galvanized steel cable, steel snap hook
- 100 ft. (30.5 m) length; 30.4 lbs. (13.8 kg)
- ANSI weight capacity 130-310 lbs., OSHA capacity up to 420 lbs.
- Meets ANSI Z359.14-2021 and OSHA 1910.140, 1910.66, 1926.502
The load indicating hook shows at a glance when the SRL has arrested a fall, useful for inspection after any incident. Manufacturer item number: FS-EX10-100-G. Sold individually.
Technical Data Sheet Class 1 Overhead SRL, Northstar Classic FS-EX10-100-G V2 (PDF)
