Description
The Safewaze 18" Energy Absorber adds 18" (0.5 m) between a harness dorsal D-ring and the next component of a fall arrest system. Built to extend the harness dorsal D-ring with a snap hook and D-ring end, it connects quickly and easily.
- Attachment points: 1 D-ring, 1 snap hook
- Length: 18" (0.5 m)
- Weight: 1.7 lbs. (.8 kg)
- Minimum breaking strength: 5,000 lbs.
- Meets ANSI Z359.13-2013; OSHA 1926.502, 1910.140, 1910.66
Attach the snap hook to the harness D-ring and connect the extended D-ring to fall-protection equipment that lacks its own energy absorber; account for the added length in free fall and clearance calculations. Manufacturer item number: FS8800SP-D.
Specifications
Attachment Points: 1 D-ring, 1 snap hook
Weight: 1.7 lbs. (.8 kg)
Length: 18" (0.5 m)
Minimum Breaking Strength: 5,000 lbs.
ANSI Weight Capacity: 130-310 lbs. (59-141 kg)
OSHA Weight Capacity: Up to 420 lbs. (191 kg)
ANSI Standards: Z359.13-2013
OSHA Standards: 1926.502, 1910.140, 1910.66
