Description
FallTech 7420 is a roofing anchor. FallTech lists it as meeting ANSI Z359.18-2017. Static strength 5,000 lb min.; ANSI User Capacity 130 to 310 lb max.; OSHA User Capacity 130 to 425 lb max. Sold individually.
FallTech 7420 specifications
| Item | FallTech data |
|---|---|
| Part number | 7420 |
| Product Type | Reusable Roof Anchor |
| Standards | OSHA 1926.502 and 1910.140; ANSI Z359.18-2017 |
| Static Strength | 5,000 lb min. |
| ANSI User Capacity | 130 to 310 lb max. |
| OSHA User Capacity | 130 to 425 lb max. |
| Base Plate | Plated Alloy Steel |
| D-Rings | Plated alloy steel; 5,000 lb min. static strength |
| Product type | Reusable Roof Anchor |
| Master pack | 4 per case |
Source: FallTech, Sell sheet (document).
Built for roof and deck anchorage applications, this rotating D-ring anchor improves worker range of motion while providing a durable permanent tie-off point for fall protection systems.
Features
- Features 10" x 10" anchoring base plate with 2-1/4" connecting D-ring
- 360 degree Swivel D-ring allows for greater movement and worker range
- Includes 16 screws for installation into wood, metal deck, steel roof, or Z-Purlin structures
- Suitable for use with appropriately rated horizontal lifelines
- Meets OSHA 1926.502 and 1910.140 regulations
- Complies with ANSI Z359.18-2017 Type A
Sold individually
The price shown is for one; quantity 1 = 1 piece.
Documents & downloads
Item Number
7420
