Description
FallTech 7446 is a concrete anchor. FallTech lists it as meeting ANSI Z359.18-2017. Static strength 6,000 lb min.; ANSI User Capacity 130 to 310 lb max.; OSHA User Capacity 130 to 425 lb max. Sold individually.
FallTech 7446 specifications
| Item | FallTech data |
|---|---|
| Part number | 7446 |
| Product type | Expansion Wedge |
| Standards | ANSI Z359.18-2017; OSHA 1926.502 and 1910.66 |
| Static Strength | 6,000 lb min. |
| ANSI User Capacity | 130 to 310 lb max. |
| OSHA User Capacity | 130 to 425 lb max. |
| Master pack | 1 |
Source: FallTech, Instruction manual (document).
This reusable concrete anchor provides a strong temporary tie-off solution for cured concrete walls and ceilings while supporting a wide range of fall protection and HLL applications.
Features
- Features forged O-ring connection point and 360 degree swiveling orientation
- Requires 4-1/2" min. hole depth and 1" max. hole diameter
- Assembled with galvanized and stainless steel components
- For temporary use in cured concrete walls and ceilings
- Suitable for use with horizontal lifeline (HLL) systems, including all FallTech HLLs
- Complies with ANSI Z359.18-2017
Sold individually
The price shown is for one; quantity 1 = 1 piece.
Documents & downloads
Product videos
Item Number
7446
