Description
Safewaze 021-4075 is a steel anchor. Safewaze lists it as meeting ANSI Z359.18-2017 and ANSI Standards. Overall length 20.5"; beam flange width range 3.5"-15"; beam flange thickness Up to 1.25". Safewaze lists Aluminum support bar and clamps with nylon rollers and jaws, plated steel D-ring, 3.1 lbs; 20.5 inch overall length; fits flanges up to 1.25 inches thick; 180 degree rotating connection point; 5,000 lb. minimum breaking strength; rated to ANSI Z359.18-2017 Type A.
Safewaze 021-4075 specifications
| Item | Safewaze data |
|---|---|
| Part number | 021-4075 |
| Material | Aluminum support bar and clamps, nylon rollers and jaws, plated steel D-ring, polyester label cover |
| Overall Length | 20.5" |
| Beam Flange Width Range | 3.5"-15" |
| Beam Flange Thickness | Up to 1.25" |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.18-2017 Type A |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Weight | 3.1 lbs. (1.4 kg) |
Source: Safewaze, Technical Data Sheet 021-4075_4hapc9 (PDF) (document).
Riding on nylon rollers, the Safewaze Sliding Beam Anchor trails along an I-beam flange from 3.5 to 15 inches wide for hands-free overhead or foot-level tie-off.
- Aluminum support bar and clamps with nylon rollers and jaws, plated steel D-ring, 3.1 lbs.
- 20.5 inch overall length; fits flanges up to 1.25 inches thick
- Single-sided jaw adjustment with a one-handed trigger for quick lock and release
- 180 degree rotating connection point
- 5,000 lb. minimum breaking strength; rated to ANSI Z359.18-2017 Type A
Replaceable jaw liners extend its service life on repeated structural steel installations. Manufacturer item number: 021-4075. Sold individually.
