Description
Safewaze 021-4081 is a concrete anchor made of zinc-plated steel. Safewaze lists it as meeting ANSI Z359.18-2017 and ANSI Standards. Minimum breaking strength 5,000 lbs.; ANSI Weight Capacity 130-310 lbs. (59-141 kg); OSHA Weight Capacity Up to 420 lbs. (191 kg). Safewaze lists Zinc-plated steel construction; 6-inch length, 3-inch width; 180-degree/360-degree swiveling D-ring; Minimum breaking strength of 5,000 lbs., meeting ANSI Z359.18-2017 Type A.
Safewaze 021-4081 specifications
| Item | Safewaze data |
|---|---|
| Part number | 021-4081 |
| Material | Zinc-plated steel |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.18-2017 Type A |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Width | 3" (76 mm) |
| Length | 6" (152 mm) |
| Weight | 0.8 lbs. (0.3 kg) |
Source: Safewaze, Technical Data Sheet 021-4081-TDS (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | Weight |
|---|---|---|---|
| 021-4081 | Concrete Anchors | Zinc-plated steel | 0.8 lbs. (0.3 kg) |
| 021-4073 | Concrete Anchors | Zinc-plated steel | 0.5 lbs. (0.2 kg) |
| 021-4072 | 10K Swivel Anchor & Concrete Wedge Bolt | High strength plated steel | 2.1 lbs. (952 g) |
| 021-4052 | 5K Swivel Anchor & Concrete Bolt | Zinc-plated steel | 2.1 lbs. (953 g) |
| 021-4082 | Concrete Anchors | Zinc-plated steel | 0.7 lbs. (0.3 kg) |
| 021-4057 | Concrete Anchors | Zinc-plated steel | 0.3 lbs. (0.1 kg) |
| 021-4054 | 5K Swivel Anchor & Concrete Wedge Bolt | High strength plated steel | 2.1 lbs. (952 g) |
| 021-4083 | Concrete Anchors | Zinc-plated steel | 0.1 lb. (0.04 kg) |
| 021-4053 | Concrete Anchors | Galvanized steel | 0.4 lbs. (0.2 kg) |
By Safewaze's published data; each part number links to its own page.
Safewaze 021-4081 questions
What is the Safewaze 021-4081? Safewaze 021-4081 is a concrete anchor made of zinc-plated steel. Safewaze lists it as meeting ANSI Z359.18-2017 and ANSI Standards.
What is the 021-4081 made of? Zinc-plated steel, per Safewaze.
Which other Safewaze part numbers are in this family? 021-4073 (concrete anchors), 021-4072 (10k swivel anchor & concrete wedge bolt), 021-4052 (5k swivel anchor & concrete bolt), 021-4082 (concrete anchors), 021-4057 (concrete anchors).
Unlike the standalone version, this 5K Swivel D-ring Anchor Assembly from Safewaze ships complete with a wedge-style concrete bolt.
- Zinc-plated steel construction
- 6-inch length, 3-inch width
- 180-degree/360-degree swiveling D-ring
- Includes a wedge-style installation bolt
- Minimum breaking strength of 5,000 lbs., meeting ANSI Z359.18-2017 Type A
- Weighs 0.8 lbs. (0.3 kg)
A complete, ready-to-install single-point anchor for concrete decks and structures. Bayshore Safety & Industrial Supplies stocks it for concrete and rebar crews setting up temporary or permanent tie-off points. Manufacturer item number: 021-4081.
