Description
Safewaze FS-EX326 is a roofing anchor made of galvanized steel. Safewaze lists it as meeting ANSI Standards. Baseplate 16" x 16" (406 mm x 406 mm); minimum breaking strength 5,000 lbs.; ANSI Weight Capacity 130-310 lbs. (59-141 kg). Safewaze lists Galvanized steel construction; 16 x 16 inch base plate; 20-inch height from base to loop; Minimum breaking strength of 5,000 lbs.
Safewaze FS-EX326 specifications
| Item | Safewaze data |
|---|---|
| Part number | FS-EX326 |
| Material | Galvanized steel |
| Baseplate | 16" x 16" (406 mm x 406 mm) |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Height | 20” (508 mm) from baseplate bottom to top of loop |
| Weight | 36 lbs. (16.3 kg) |
Source: Safewaze, Technical Data Sheet FS-EX325-FS-EX326-TDS (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | Minimum Breaking Strength | OSHA Standards |
|---|---|---|---|---|
| FS-EX326 | Roofing Anchors | Galvanized steel | 5,000 lbs. | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| FS-EX325 | Roofing Anchors | Galvanized steel | 5,000 lbs. | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| FS-EX310-1 | Roofing Anchors | Zinc plated steel anchor, stainless steel fasteners | 5,000 lbs. | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| FS-EX311 | Roofing Anchors | Zinc-plated steel | 3,600 lbs. perpendicular to the seam; 5,000 lbs. parallel to the seam | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
By Safewaze's published data; each part number links to its own page.
Safewaze FS-EX326 questions
What is the Safewaze FS-EX326? Safewaze FS-EX326 is a roofing anchor made of galvanized steel. Safewaze lists it as meeting ANSI Standards.
What is the FS-EX326 made of? Galvanized steel, per Safewaze.
Which other Safewaze part numbers are in this family? FS-EX325 (roofing anchors), FS-EX310-1 (roofing anchors), FS-EX311 (roofing anchors).
This 18-inch galvanized post anchor from Safewaze provides a taller, fixed tie-off point for wood, steel, or concrete roof structures.
- Galvanized steel construction
- 16 x 16 inch base plate
- 20-inch height from base to loop
- Minimum breaking strength of 5,000 lbs.
- OSHA-rated capacity up to 420 lbs.
- Weighs 36 lbs. (16.3 kg)
Works as a single anchor point or as part of a horizontal lifeline system on permanent installations. Bayshore Safety & Industrial Supplies stocks it for roofing contractors who need a dependable rooftop anchor point. Manufacturer item number: FS-EX326.
