Description
Safewaze 020-4026 is a roofing anchor. Safewaze lists it as meeting ANSI Standards. Material thickness 0.04" (1 mm); plate width 1.9" (48 mm); number of holes 14. Safewaze lists Yellow zinc-plated and stainless steel construction, 1.3 lbs; 18 inch length with 14 mounting holes, 0.18 inch hole diameter; 5,000 lb. minimum breaking strength; ANSI weight capacity of 130-310 lbs., OSHA weight capacity up to 420 lbs.
Safewaze 020-4026 specifications
| Item | Safewaze data |
|---|---|
| Part number | 020-4026 |
| Material | Yellow zinc-plated steel, stainless steel |
| Material Thickness | 0.04" (1 mm) |
| Plate Width | 1.9" (48 mm) |
| Number of Holes | 14 |
| Hole Diameter | 0.18" (4.5 mm) |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Length | 18" (457 mm) |
| Weight | 1.3 lbs. (.6 kg) |
Source: Safewaze, Technical Data Sheet 020-4026 (PDF) (document).
Related Safewaze part numbers
| Part number | Version | Material | Material Thickness | Plate Width |
|---|---|---|---|---|
| 020-4026 | Roofing Anchors | Yellow zinc-plated steel, stainless steel | 0.04" (1 mm) | 1.9" (48 mm) |
| 020-4025 | Roofing Anchors | Yellow zinc-plated steel, stainless steel | 0.04" (1 mm) | 1.9" (48 mm) |
| 020-4027 | Roofing Anchors | Yellow zinc-plated steel, stainless steel | 0.04" (1 mm) | 1.9" (48 mm) |
By Safewaze's published data; each part number links to its own page.
Safewaze 020-4026 questions
What is the Safewaze 020-4026? Safewaze 020-4026 is a roofing anchor. Safewaze lists it as meeting ANSI Standards.
What is the 020-4026 made of? Yellow zinc-plated steel, stainless steel, per Safewaze.
Which other Safewaze part numbers are in this family? 020-4025 (roofing anchors), 020-4027 (roofing anchors).
Designed for permanent installation between the roof peak and the eaves, the Safewaze Permanent Roof Anchor gives residential roofing contractors a fixed, low-profile tie-off point on wood roof structures.
- Yellow zinc-plated and stainless steel construction, 1.3 lbs.
- 18 inch length with 14 mounting holes, 0.18 inch hole diameter
- 5,000 lb. minimum breaking strength
- ANSI weight capacity of 130-310 lbs., OSHA weight capacity up to 420 lbs.
- Meets OSHA 1926.502, 1910.140 and 1910.66
The extra mounting holes spread the load across more roof structure for a longer-lasting anchorage on new construction or re-roofing jobs. Includes (14) 16D roofing nails. Manufacturer item number: 020-4026. Sold individually.
