Description
Safewaze 021-4055 is a steel anchor. Safewaze lists it as meeting ANSI Z359.18-2017 and ANSI Standards. Overall length 19.5"; beam flange width range 4"-13"; beam flange thickness Up to 1.25". Safewaze lists Aluminum support bar and clamps with plated steel jaws, stainless and plated steel D-ring, 4 lbs; 5,000 lb. minimum breaking strength; rated to ANSI Z359.18-2017 (Type A).
Safewaze 021-4055 specifications
| Item | Safewaze data |
|---|---|
| Part number | 021-4055 |
| Material | Aluminum support bar and clamps, plated steel jaws, stainlless steel and plated steel D-ring, polyester label cover |
| Overall Length | 19.5" |
| Beam Flange Width Range | 4"-13" |
| Beam Flange Thickness | Up to 1.25" |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| ANSI Standards | ANSI Z359.18-2017 (Type A) |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Weight | 4 lbs. (1.8 kg) |
Source: Safewaze, Technical Data Sheet 021-4055 (PDF) (document).
The Safewaze Premier Sliding Beam Anchor combines a full 180/360 degree swivel D-ring with reinforced jaw liners for smooth, hands-free trailing along an overhead I-beam.
- Aluminum support bar and clamps with plated steel jaws, stainless and plated steel D-ring, 4 lbs.
- Fits beam flanges from 4 to 13 inches wide, up to 1.25 inches thick; 19.5 inch overall length
- Dual adjustment jaws with a one-handed lock-and-release trigger
- 5,000 lb. minimum breaking strength; rated to ANSI Z359.18-2017 (Type A)
A protective label cover keeps compliance markings legible through repeated overhead or foot-level tie-off use. Manufacturer item number: 021-4055. Sold individually.
