Description
Safewaze 018-4001 is a steel anchor. Safewaze lists it as meeting EN 795:1996 and ANSI Standards. Beam flange width range 3.5"-14"; beam flange thickness Up to 1.75"; minimum breaking strength 5,000 lbs. Safewaze lists Aluminum body with stainless steel rail guides and a coated steel D-ring, 7.1 lbs; Fits beam flange widths from 3.5 to 14 inches, up to 1.75 inches thick; Abrasion, heat and chemical-resistant Ertalon nylon wheels; 5,000 lb. minimum breaking strength; ANSI weight capacity 130-310 lbs., OSHA up to 420 lbs.
Safewaze 018-4001 specifications
| Item | Safewaze data |
|---|---|
| Part number | 018-4001 |
| Material | Aluminum; stainless steel; Ertalon® nylon wheels; Coated steel D-ring |
| Beam Flange Width Range | 3.5"-14" |
| Beam Flange Thickness | Up to 1.75" |
| Minimum Breaking Strength | 5,000 lbs. |
| ANSI Weight Capacity | 130–310 lb (59–141 kg) |
| OSHA Weight Capacity | Up to 420 lb (191 kg) |
| OSHA Standards | OSHA 1910.140; OSHA 1910.66; OSHA 1926.502 |
| Other Standards | CE 0321, EN 795:1996 (+A1:2000) Class B |
| Weight | 7.1 lbs. (3.2 kg) |
Source: Safewaze, Technical Data Sheet 018-4001-TDS (PDF) (document).
The Safewaze Beam Trolley Anchor rides along an overhead I-beam on nylon wheels, letting a worker keep a continuous tie-off point while moving down the beam.
- Aluminum body with stainless steel rail guides and a coated steel D-ring, 7.1 lbs.
- Fits beam flange widths from 3.5 to 14 inches, up to 1.75 inches thick
- Abrasion, heat and chemical-resistant Ertalon nylon wheels
- 5,000 lb. minimum breaking strength; ANSI weight capacity 130-310 lbs., OSHA up to 420 lbs.
- Certified to CE 0321 and EN 795:1996 (+A1:2000) Class B
Its smooth-rolling design suits steel fabrication and food processing facilities with overhead I-beam runs. Manufacturer item number: 018-4001. Sold individually.
